Telemetry Data Recording and Processing Systems – a 25+ year heritage. The Parraid Telemetry and Data Systems offering has grown to include the most feature rich ground based data processing and recording systems in the world for use in all data processing applications. Our current capabilities include:
Parraid is a world-class provider of telemetry receiving, processing, recording, archiving, and mining solutions to government and industry on six continents. Our continued range of applications includes flight test, laboratory test, operational test, simulation, satellite command and control, and launch vehicle command and control.
Edge² delivers network telemetry processing in a compact 2-channel unit. Supports RF-to-Ethernet (200 MHz-5.15 GHz), TMoIP/IRIG 106 Ch10/11 output. Portable or 1U rack-mountable design.
The IMUX G2e and the IMUX G2e Hybrid (G2eH) have many unique features such as supporting all industry-standard telemetry signal types, the ability to record two Chapter 10 files simultaneously.
OMEGA-NExT: 64-bit telemetry processing software with intuitive UI. Supports Chapter 10, TMoIP, and Ethernet inputs. Includes Clarity vector display for real-time and playback visualization.
Series-5000: Real-time telemetry platform with 2-16 PCM inputs, optional Bit Syncs/RF receivers, IRIG time-stamping, and hot mic audio. Available in portable and rack-mount 2U/4U configurations.
Best Data Engine (BDE) compares multiple PCM input channels and creates a composite output with the best data. Real-time stream selection and error correction for mission-critical telemetry.
BSR-100 provides seamless Best Source post-processing, handling up to 32 recorded PCM streams from multiple locations. Includes 2-channel PSIMe output for optimal data reproduction.
The G3 Recorder-Processing system represents the next generation of telemetry data recording and processing platforms.
IMUX RE/CON is a telemetry ground network recorder for IP ranges. Auto-detects packets, converts formats to IRIG 106 Ch10 on-the-fly, and supports network playback redirection.
OMEGA Data Environment (ODE) post-processing enables rapid, secure mining of large data sets. Uses OODM technology for fast access, supports collaboration, and provides FIPS-compliant network encryption.
Rx2 multi-channel receiver: Tri-band (L/S/C) RF-to-Ethernet with AM, PCM/FM, BPSK, SOQPSK-TG demods. Up to 14 receivers per chassis, Chapter 10/11 output, and built-in diversity combining.
Connect With Our Team
All Parraid systems are designed, built, and supported in the United States. Our team of engineers and specialists provides continuous technical support to ensure mission reliability and customer success.
Powering secure, real-time data transmission across land, sea, and sky.
Parraid delivers mission-critical telemetry and tactical communications solutions designed to perform when failure is not an option.
